RB-H6-3626-12
RBT
8465990000
1. Dual-Rotation High-Capacity Spindle:
Upon evaluating your business requirements, we will recommend the most suitable 5-axis spindle unit for your specific needs.
2. 5-Axis Motion Controller with RTCP function:
RTCP (Rotation Tool Center Point) Function maintains rotary axes at a constant angle between tool and surface to be machined. It is a crucial difference between real (simultaneous) and fake (3+2) 5-axis CNC systems.
3. Rigorously Tempered Welded Steel Framework:
These steel frameworks are fortified with substantial ribs to counteract deflection and minimize vibration. The essential structures undergo a stress-relief process in our in-house tempering oven.
4. Precision Ball Screw Actuation System:
Ball screws offer reduced friction and tight contact, resulting in greater mechanical efficiency and enhanced re-positioning precision, while also reducing the need for frequent lubrication of the 5 axis cnc machining center.
5. Automated Tool Change (ATC) and Calibration System:
The 5-Axis machining process is fully automated with tool changing and calibration, enabling seamless and uninterrupted processing of parts in a single setup.
6. Diverse Table Configurations:
A range of machine table configurations is available (Aluminum, Steel, Cast Iron), featuring T-Slots, flat surfaces, or bespoke tables and jigs tailored to specific requirements.
7. Utilizing a laser interferometer, we meticulously calibrate our 5-axis machining centers to ensure unparalleled precision, guaranteeing accuracy and reliability in complex machining operations.
8. Offer comprehensive dust collection solutions for 5-axis machining centers, efficiently capturing and filtering debris, ensuring a clean, safe, and optimal working environment.
Technical parameters
No. | items | parameter | No. | items | parameter |
1 | product name | 5 Axis Cnc Machining Center with Rotary Twin Table | 9 | Z axis maximum speed | 20m/min |
2 | model | RB-F5-3323-Z10 | 10 | Repeat accuracy (within 300mm) | ±0.05mm |
3 | X axis effective stroke | 3250mm | 11 | voltage | 380V |
4 | Y axis effective stroke | 2250mm | 12 | total power | 25.35KW |
5 | Z axis effective stroke | 1000mm | 13 | spindle power | 17KW(customizable） |
6 | B-axis rotation angle | ±120° | 14 | Frequency | 50HZ |
7 | C-axis rotation angle | ±540° | 15 | weight | 12T |
8 | X/Y axis maximum speed | 40m/min | 16 | size |
Applicable industries and materials
Industries: Mold manufacturing, composite material processing, and thick sheet thermoforming processing in industries such as aerospace, rail transit, automotive interior and exterior,energy and building, marine, packing, medical, patterns and moulds, and sanitary ware.
Materials: Different types of composite materials include carbon fiber, glass fiber, and carbon/carbon. Plastics such as ABS, PVC, PC, PP, PS, PE, PET, HDPE, PETG, and acrylic are also commonly used. Additionally, there are other materials like high-density sponge, styrofoam foam, wood, stone, plaster, MDF, and resin. Soft metals like aluminum, copper, and zinc, as well as aluminum/paper honeycomb, are also utilized.
RBT factory production site and team
